| Chassies | Made From 125 X 65 Heavy Channel. | |
| Cabine | Made From 18 Gauge Sheet & Sliding Door Type. | |
| Engine | Diseal 8 H.P. Air Cooled RajkotMfg”s. | |
| Hopper | Made From 10 Gauge Sheet. | |
| Drum | 10/7 Cft Capacity Casting Drum & Baring With Bush Type. | |
| Drum Cap | Made From 8 Gauge Sheet With Steel Blade. | |
| Tyre | 500 X 19 Tyre. | |
| Jack | Hydraulics Jack 3 Ton Capacity. | |
| Walve | Control Walve. | |
| Capacity | 10/7 cu.Ft(one bag) | |
| Weight | 1500 kg | |
| Power | 6 HP Air Cooled Diesel Engine 0r 5 HP Electric Motor (AS well combine) | |
| Wheel | 600/6 Pneumatic wheel | |
| Chasis | 5” C Channel | |
| Kanchi | 65 x 65 x 8 L Angle | |
| Hopper & cone | 10 guage sheet | |
| Engine Cabin | 14 guage sheet with Angle frame 35 X 35 X5 Angle | |
| Capacity (Un Fixed) | 180Ltrs. / 5CFT . | |
| Capacity ( Mixed ) | 100 Ltrs / 5 CFT. | |
| Drum Speed R.P.M | 20 / 22 | |
| Thickness Of Drum Cone | 3.15 mm | |
| Drum & Mixing Blade | Indivisually renewable | |
| Size of Drum Opening | 335mm | |
| Drum | Cast iron G.M Bushes fitted centrally. | |
| Drum Support | Cast Iron yoke & Stearing plate with cast iron pedastal. | |
| Frame & Chasis | Rigid steel | |
| Transmission | "V" Belt / Roller / Chain | |
| Powered by | 3.5 H.P Air colled Desiel Engine | |
| Type | Tilting. | |
| Capacity unmixed in litres/cft | 180 / 5 | |
| Capacity Mixed in litres/cft | 100 / 3.5 | |
| Drum Speed R.P.M. | 14 / 16 | |
| Thickness Of Drum Cone in mm | 3.15 | |
| Drum Cone & Mixing blade | Individually renewable | |
| Size of Drum opening In mm. | 350 | |
| Drum | Cast Iron G.M. Bushes Fitted Centrally | |
| Drum Support | Cast Iron Yoke & Stearing Plate With Cast Iron Pedestal | |
| Frame and Chassis | Rigid all steel constructions | |
| Discharge height in mm. | 700 | |
| Transmission | Roller chain | |
| Powered by | 2.H.P. Electric Motor OR 3.5 HP Diesel Engine | |
| Wheels | Hand Cart Wheels OR Scooter Tyres | |
| Approx. weight of basic | 240 kg | |
| Capacity (Un Fixed) | 180Ltrs. / 5CFT. | |
| Capacity ( Mixed ) | 100 Ltrs / 5 CFT. | |
| Drum Speed R.P.M | 20 / 22 | |
| Thickness Of Drum Cone | 3.15 mm | |
| Drum & Mixing Blade | Indivisually renewable | |
| Size of Drum Opening | 350mm | |
| Drum | Cast iron G.M Bushes fitted centrally. | |
| Drum Support | Cast Iron yoke & Stearing plate with cast iron pedastal. | |
| Frame & Chasis | Rigid steel | |
| Transmission | "V" Belt & Pulley | |
